PF115B+ is a subwoofer used in fixed installation such as multi-functional hall, museum, house of worship, commercial announcement, etc.
PF115B+ adopts customized Audiocenter 15”LF driver with 4”voice coil.
Optimized cabinet phase structure ensures high SPL, also improves sound quality and performance.
The tongue and groove cabinet is CNC made Russian birch plywood, which ensures few resonances. And the compact cabinet enables the speaker to “hide” at any corner of the room.
|Frequency Response(-6dB anechoic chamber)||35Hz-300Hz|
|LF Driver||Customized Audiocenter ferrite driver, 4”voice coil, 700W(AES)|
|Pole Mount||Base hole \u044435mm|
|Input Connectors||2xNEUTRIK® NL4MP|
|Cabinet Material||Russian birch plywood CNC made|
|Cabinet Color||Black is standard and default color.Consult with sales team for the other customized colors|
