A coming soon new digital mixer from Topp Pro. The new DM48.20 is a significant step up digital mixing console with the goal to combine the best design of a mixing console with advanced modern technology, easy to operate and set up, and completely redefine all the functions of a mid-sized live mixer.
DM48.20 digital audio mixing console is a multi-channel channel inputs digital mixer principally dedicated to live applications; however it is an incredible tool for fixed installations through a very powerful signal processing. The AUX bus architecture offers flexibility for monitoring or effects send. The analog type surface is equipped with large motorized faders showing instantly the level of signal or parameters to be edited. The touch screen helps to visualize and edit the parameters very quickly. A large number of physical buttons andsliders give a direct access to parameters as well, and are an alternative to the touch functionality of the screen. Other useful remote controls are available through Ethernet port. A tablet App can also be used for wireless control. The mixer features other extended possibilities to communicate with external equipment like an optional Dante card for audio transport.
Inputs: 32 x XLRs extendable to 48 via 2 units DIO.24
Phantom Power: 32 x Channels
Outputs: 2 x XLR Main, 16 x XLR Aux & 2 Ctrl Out XLR
Busses/Groups: 20 total (16 x bus, main LR & Ctrl Out)
Data I/O: 1 x Ethernet
USB: 1 x Type A
Computer Connectivity: N/A
I/O Expansion Slots: 1 x slot DANTE network (optional and not included)
Faders: 17 x 100mm (motorized)
A/D Resolution: 24-bit / 48kHz / 96 kHz
EQ Bands: 4-band EQ, 1 LPF, 1 HPF
Signal Processing: Gate, Compressor
Features: 1 x 4-pin XLR (lamp)
DAW Integration: Via DANTE Virtual Soundcard (not included)
Screen: 10 inch color LCD touch screen
