The CX15A is a coaxial stage monitor designed specifically for live sound, even if the very compact, low-profile enclosure makes it suitable also for theater and television applications. The combination of a high-performance coaxial transducer, a carefully designed cabinet and powerful electronics provides a very high SPL before feedback and a great intelligibility even at very high power.
| SYSTEM
|
|
| System Type |
2-way processed coaxial active enclosure |
| Frequency Response (±3dB) |
60 Hz – 18kHz (Processed) |
| Horizontal Coverage Angle |
80° (-6dB) |
| Vertical Coverage Angle |
80° (-6dB) |
| Maximum Peak SPL @ 1m |
131dB |
| |
|
| TRANSDUCERS
|
|
| LF |
One 15” (380mm), 3” (75mm) Interleaved Voice Coil, 8 Ohm |
| HF |
One 1.4” driver, 2.4” (60mm) edgewound aluminium voice coil, titanium diaphragm, 8 Ohm |
| |
|
| ELECTRICAL
|
|
| Input Impedance |
20 kΩ balanced, 10 kΩ unbalanced |
| Input Sensitivity |
+4dBu / 1.25 V |
| Signal Processing |
CORE processing, 96kHz / 40bit floating point SHARC DSP, 24 bit AD/DA converters |
| Direct access Controls |
4 Presets (Normal Wedge/Coupled Unit/Low Cut, User), Network Termination, GND Link |
| Remote Controls |
PRONET control software |
| Network protocol |
CANBUS |
| Amplifier Type |
Class D with SMPS, Variable Switching Frequency |
| Output Power |
2000W |
| Mains Voltage Range (Vac) |
230V ±15% - 115 ±15% 50/60Hz (internally selectable) |
| IN / OUT Connectors |
Neutrik XLR-M / XLR-F |
| IN / OUT Network Connectors |
ETHERCON®(NE8FAV) |
| Mains Connector |
PowerCon® (NAC3MPA) |
| Mains Link Connector |
PowerCon® (NAC3MPB) |
| Cooling |
Variable speed DC fan |
| |
|
| ENCLOSURE & CONSTRUCTION
|
|
| Physical Dimensions |
|
| Width |
520 mm (20.47”) |
| Height |
336 mm (13.22”) |
| Depth |
415 mm (16.33”) |
| Monitor Taper |
45° or 55° |
| Enclosure Material |
15mm, reinforced Phenolic Birch |
| Paint |
High resistance, water based paint |
| Pole holder |
1 x side, dual-angle |
| Net Weight |
18.5 Kg (40.78 lbs.) |
